Naval Architecture

Builder's Construction Plans

Historically accurate period-style builder's drawings for all 42 documented Cayman Islands-built schooners, scaled from the Goldfield master plans by gross tonnage from maritime records.

Scale 1/4" = 1'-0"•Reference: Goldfield (85 GT, 85 ft LOA)•Period: 1850–1947
Sort:

Showing 42 vessels — sorted by tonnage

Builder's plan — Envoy
17 GT

Envoy

1936 · Cayman Brac32 ft LOA
Foster Shipyard
Builder's plan — Genevra
18 GT

Genevra

1918 · Grand Cayman34 ft LOA
Unknown
Builder's plan — K. H. Ruby
19 GT

K. H. Ruby

1936 · Cayman Brac33 ft LOA
Foster Shipyard
Builder's plan — Colburn
20 GT

Colburn

1932 · Grand Cayman34 ft LOA
Arch Brothers
Builder's plan — Accord
21 GT

Accord

1930 · Grand Cayman35 ft LOA
Arch Brothers
Builder's plan — Fair Weather
22 GT

Fair Weather

1935 · Grand Cayman35 ft LOA
Cayman Boats Ltd.
Builder's plan — Amity
23 GT

Amity

1938 · Grand Cayman36 ft LOA
Arch Brothers
Builder's plan — Armistice
27 GT

Armistice

1930 · Grand Cayman55.8 ft LOA
James Arch
Builder's plan — Olga
44 GT

Olga

1926 · Grand Cayman67.5 ft LOA
Arch Brothers
Builder's plan — Majestic
47 GT

Majestic

1922 · Grand Cayman69.5 ft LOA
J. R. Bodden Sr.
Builder's plan — W. Bloomfield
49 GT

W. Bloomfield

1909 · Grand Cayman70.6 ft LOA
Arch Brothers
Builder's plan — Miss C. B.
52 GT

Miss C. B.

1933 · Cayman Brac71.7 ft LOA
Foster Shipyard
Builder's plan — W. C. Hicks
53 GT

W. C. Hicks

1924 · Grand Cayman72 ft LOA
Arch Brothers
Builder's plan — Georgiana
55 GT

Georgiana

1925 · Grand Cayman73 ft LOA
Arch Brothers
Builder's plan — Carolie
57 GT

Carolie

1920 · Grand Cayman73 ft LOA
Arch Brothers
Builder's plan — Carolie II
58 GT

Carolie II

1935 · Grand Cayman74.3 ft LOA
Arch Brothers
Builder's plan — Kirk B
59 GT

Kirk B

1934 · Cayman Brac74.7 ft LOA
Kirkconnell Yard
Builder's plan — E. M. Bertha
61 GT

E. M. Bertha

1927 · Grand Cayman75.5 ft LOA
Arch Brothers
Builder's plan — C. C. Acme
62 GT

C. C. Acme

1917 · Grand Cayman76 ft LOA
Arch Brothers
Builder's plan — Lydia E. Wilson
63 GT

Lydia E. Wilson

1931 · Grand Cayman76.9 ft LOA
Elroy Arch
Builder's plan — Homeward Bound
66 GT

Homeward Bound

1928 · Grand Cayman78.5 ft LOA
Arch Brothers
Builder's plan — Genevieve
67 GT

Genevieve

1926 · Grand Cayman79 ft LOA
Arch Brothers
Builder's plan — Rembro
68 GT

Rembro

1930 · Grand Cayman79.4 ft LOA
Arch Brothers
Builder's plan — T. B. Gain
71 GT

T. B. Gain

1929 · Grand Cayman80.7 ft LOA
Arch Brothers
Builder's plan — T. B. Radar
71 GT

T. B. Radar

1938 · Grand Cayman80.7 ft LOA
Scott Shipyard
Builder's plan — Expediter
74 GT

Expediter

1927 · Grand Cayman81.5 ft LOA
Arch Brothers
Builder's plan — Edison
76 GT

Edison

1921 · Grand Cayman82.4 ft LOA
Arch Brothers
Builder's plan — Exploit
76 GT

Exploit

1916 · Grand Cayman82.4 ft LOA
Arch Brothers
Builder's plan — Taylor
78 GT

Taylor

1923 · Grand Cayman83 ft LOA
Arch Brothers
Builder's plan — Sturdee
84 GT

Sturdee

1921 · Grand Cayman84.8 ft LOA
Arch Brothers
Builder's plan — Goldfield
85 GT

Goldfield

1930 · Grand Cayman85 ft LOA
Arch Brothers
Builder's plan — Cayman Star
87 GT

Cayman Star

1933 · Grand Cayman86 ft LOA
Arch Brothers
Builder's plan — Harmony
88 GT

Harmony

1924 · Cayman Brac85.6 ft LOA
Arch Brothers
Builder's plan — Zirema
91 GT

Zirema

1932 · Grand Cayman87.5 ft LOA
McTaggart Shipyard
Builder's plan — Coronella
92 GT

Coronella

1918 · Grand Cayman87.7 ft LOA
Arch Brothers
Builder's plan — Cayman Pride
95 GT

Cayman Pride

1931 · Grand Cayman88.5 ft LOA
Arch Brothers
Builder's plan — A. M. Adams
116 GT

A. M. Adams

1925 · Grand Cayman94 ft LOA
Arch Shipyard
Builder's plan — Admiral Beatty
123 GT

Admiral Beatty

1919 · Grand Cayman96 ft LOA
Arch Brothers
Builder's plan — Explicit
187 GT
3-Mast

Explicit

1920 · Grand Cayman108 ft LOA
Ritch Brothers
Builder's plan — Clara C. Scott
198 GT
3-Mast

Clara C. Scott

1922 · Cayman Brac110 ft LOA
J. E. Scott & Bros.
Builder's plan — Cayman Queen
210 GT
3-Mast

Cayman Queen

1929 · Grand Cayman112 ft LOA
Arch Brothers
Builder's plan — O. Louise
231 GT
3-Mast

O. Louise

1919 · Grand Cayman116 ft LOA
Arch Shipyard
